officedweller · #**2561** Posted **Feb 5, 2024, 11:31 PM**

Posted today on Broadway Subway twitter:

Quote:

This past Friday afternoon, TBM Phyllis launched from South Granville Station! She is now on the final leg of her journey to Cypress St, where she will be dismantled and removed.

madog222 · #**2562** Posted **Feb 5, 2024, 11:47 PM**

That should mean Elsie will arrive at Hemlock this week. Phyllis's arrival at Cypress should be around March 20th.

officedweller · #**2563** Posted **Feb 7, 2024, 8:27 AM**

https://twitter.com/broadwaysubway_

HighSpeedUrbanist · #**2564** Posted **Feb 10, 2024, 5:37 AM**

Elsie arrived at South Granville today!

https://twitter.com/broadwaysubway_/status/1756078160720921072

madog222 · #**2565** Posted **Feb 10, 2024, 5:50 AM**

That’s makes it an average of 14m/day for that leg.

Hooknose · #**2566** Posted **Feb 10, 2024, 12:33 PM**

Quote:

Originally Posted by HighSpeedUrbanist

Elsie arrived at South Granville today!

https://twitter.com/broadwaysubway_/status/1756078160720921072

The horses have made the final turn and are heading for the wire.

Once Elsie starts the final leg (3 to 4 weeks), it is a race to the finish.

A "well done" to all the crews working this project.

dpogue · #**2567** Posted **Feb 15, 2024, 2:41 AM**

A bunch of recent photos have been uploaded to the MOTI Flickr page: https://www.flickr.com/photos/tranbc/

officedweller · #**2568** Posted **Feb 15, 2024, 7:15 PM**

From the project twitter.

At Arbutus Staion waiting for the TBMs to arrive.

2 steel rings, called "shuttering rings," are installed in the east wall of the future Arbutus Station.
As crews pour the concrete wall at this end of the station, the rings provide support.
They will also protect the wall when the tunnel boring machines break through.
https://twitter.com/broadwaysubway_

Jimbo604 · #**2569** Posted **Feb 22, 2024, 2:44 AM**

Src: Broadway Subway Project Twitter 10:03 AM · Feb 21, 2024

"Since this photo was taken in November, concrete has been poured here to create a slanted floor.

This is where underground stairs and escalators will connect the Canada Line to the Millennium Line at Broadway-City Hall Station."

Also, re previous post, did they use those rings on the other stations, I don't remember them, but I may have just missed them.

madog222 · #**2570** Posted **Feb 22, 2024, 3:13 AM**

Yes they were previously used at Granville. Arrivals at the other stations were before the station box walls were poured so the shuttering rings weren't needed.

jollyburger · #**2571** Posted **Feb 22, 2024, 4:33 AM**

Quote:

Originally Posted by madog222

Yes they were previously used at Granville. Arrivals at the other stations were before the station box walls were poured so the shuttering rings weren't needed.

From the Broadway Project Facebook

Quote:

These rings are installed in completed station walls where TBMs will break through and launch.

The rings will be permanent part of stations where east or west walls are completed prior to TBM arrival. The spokes in the middle provide temporary support while walls are built, but are removed before TBM breakthroughs.

Shuttering rings are required at Broadway-City Hall, South Granville, and Arbutus Stations.

The rings protected the completed station walls when TBM Phyllis broke through at South Granville on December 20.

Jimbo604 · #**2572** Posted **Feb 23, 2024, 4:04 PM**

Src: imgflip

SSP'ers impatiently waiting for Arbutus arrival...

Quote:

Originally Posted by madog222

Yes they were previously used at Granville. Arrivals at the other stations were before the station box walls were poured so the shuttering rings weren't needed.

Holy tunnel accuracy, gotta be right on the money to hit center of the ring and at exactly the right angle. Impressive.

madog222 · #**2573** Posted **Feb 26, 2024, 1:07 PM**

View into the tunnel from Broadway-City Hall station looking east showing the incline grade. Picture is from November.

Broadway Subway Project-Broadway-City Hall Station by B.C. Ministry of Transportation and Infrastructure, on Flickr

RedArbutus · #**2574** Posted **Feb 26, 2024, 5:47 PM**

Quote:

Originally Posted by madog222

View into the tunnel from Broadway-City Hall station looking east showing the incline grade. Picture is from November.

Cool shot!

officedweller · #**2575** Posted **Feb 26, 2024, 9:10 PM**

Cool.
Weird that there's that much of a dip at Broadway City Hall Station, but could be to go under Canada Line, then rising back up for the remainder of the stations.

idunno · #**2576** Posted **Feb 26, 2024, 10:37 PM**

That, and Broadway/Main St is at a higher elevation than Broadway/Cambie

officedweller · #**2577** Posted **Feb 26, 2024, 11:21 PM**

Quote:

Originally Posted by idunno

That, and Broadway/Main St is at a higher elevation than Broadway/Cambie

Ah good point - I missed the part about it facing east.

Vantage · #**2578** Posted **Feb 27, 2024, 10:41 AM**

Why does it take 4 months for the Ministry to upload these photos to Flickr? Photo taken in late November, but only uploaded last week.

scryer · #**2579** Posted **Feb 27, 2024, 6:33 PM**

Quote:

Originally Posted by Vantage

Why does it take 4 months for the Ministry to upload these photos to Flickr? Photo taken in late November, but only uploaded last week.

Maybe there's a clause about publishing photos publicly for security purposes

?

mcj · #**2580** Posted **Feb 27, 2024, 6:53 PM**

Quote:

Originally Posted by Vantage

Why does it take 4 months for the Ministry to upload these photos to Flickr? Photo taken in late November, but only uploaded last week.

Probably requires the approval of various people who have other priorities. This is the case for any large organization concerned with its' public image. Add in the fact that the government isn't exactly known for bureaucratic efficiency and...
