And they're using these toothpicks instead of caissons?

This actually works??

[ardecila]

Originally Posted by denizen467

And they're using these toothpicks instead of caissons?

This actually works??

Of course it works. Many Chicago landmarks are built with similar foundations, and lots of those are heavy masonry buildings.

They're gonna do this over the entire site, ending up with hundreds of these pilings. If they did it with caissons, there would only be 20-30 caissons drilled. Since the number of pilings is greater, each one carries less weight and doesn't need to be as beefy. You can either lie on a bed of hundreds of nails or stand on stilts; same principle.

A piling foundation is better in unstable soil. One failed nail is no big deal, but you're screwed if one of your stilts fails.

[jet cm]

Originally Posted by harryc

The pit, for the core mat. The odd cement blocks were where the central shaft is now

Sorry can't help with what the blocks were for.

Not sure what this is - - an alternative to building the entire mat out of re-bar ?

The channel lattice is just to hold up the top load of rebar. I saw similar setups in Japan but this is my first time to see this in Chicago. My current job had two ten foot thick mats and the standees we used were kind of shaky. I commented to our ironworkers that I'd feel more comfortable with something like your picture but we got the pours made with no problems.

I continue to be amazed by your interesting pics and hope you can keep it up for a long time.

[denizen467]

Originally Posted by ardecila

Of course it works. Many Chicago landmarks are built with similar foundations, and lots of those are heavy masonry buildings.

They're gonna do this over the entire site, ending up with hundreds of these pilings. If they did it with caissons, there would only be 20-30 caissons drilled. Since the number of pilings is greater, each one carries less weight and doesn't need to be as beefy. You can either lie on a bed of hundreds of nails or stand on stilts; same principle.

A piling foundation is better in unstable soil. One failed nail is no big deal, but you're screwed if one of your stilts fails.

That works if the nails are assured of being vertical and have enough lateral support that they don't start tipping/bending over as time goes by. If the soil is unstable, sounds like you're screwed with the nails too.
Also, Chicago's heavy masonry buildings were not residential buildings having 1000 people living in them; the attention to be paid to longevity/safety in this situation in 2007 is going to be greater.
