Stockholm Transport compilation thread

[Swede]

The upcoming new subway cars, C30, have gotten a design award!

https://chi-athenaeum.org/transportation-2016/2016/12/05/exterior-for-metro-stockholm-2015-2016/
http://www.stockholmdirekt.se/nyheter/st...detaljerna/repqbf!XmMV3YZjdTGO7hDlLl2gg/

images from the second link:






The cars will start being delivered this year and testing to start next year at the latest. They'll only run on the Red line and will be ready for driverless operations (will probably happen once there's only these new cars on the Red line and after some tests).

[Busy Bee]

These look great! They remind me of the original concept for the new BART cars before they got so watered down, which is pretty much par for the course here in the US. I've made the comment before that the old BART cars designed in the 60s actually seem more modern than the new ones.

Anyways, you can can always count on Sweden to be successful when it comes to good design, so congrats!

[M II A II R II K]

I guess the drivers won't have to wear short shorts with those trains.

[Swede]

I'm a bit surprised the design has actually improved through the process. The paint job is better now than at first; cleaner and more like the current generation of commuter trains. makes me wonder if they'll re-paint the C20 trains to look like this too when those get a mid-life renovation in the next few years - I'll ask SL if that's what's going to happen!

[Swede]

A couple of films showing the planned 4-tracking of Mälarbanan (the line going from Stockholm to the northwest (towards Västerås & Oslo) from Huvudsta-Duvbo (i.e. through the City of Sundbyberg and parts of the City of Solna. Since the right of way is too narrow for part of the stretch it'll be lowered into a tunnel for that bit, including Sundbyberg Station. This bit is at the heart of the Sundbyberg downtown area and will be amazing since the railway now cuts that area in half.

• Video Link

• Video Link

Originally Posted by M II A II R II K

I guess the drivers won't have to wear short shorts with those trains.

bah! Traditionally they wear skirts if it gets too warm.
/nah, that's just a few bus/train drivers who've protested against there not being shorts in the uniform wardrobe - but there are skirts. So they used skirts.

http://www.thelocal.se/20130610/48414


afaik there's now shorts as part of the uniforms.

[Swede]

The entrance to the commuter trains from the Blue line subway platforms at T-centralen. Open for use in less than 6 months.

source: facebook

[Swede]

On Saturday there was a one-time only Tunnel Run in the servicetunnel for Citybanan.
some pictures from the projects flickr:


_MG_8647 by Projekt Citybanan, on Flickr


_MG_8596 by Projekt Citybanan, on Flickr


_MG_8817 by Projekt Citybanan, on Flickr


_MG_9032 by Projekt Citybanan, on Flickr


_MG_8935 by Projekt Citybanan, on Flickr


_MG_8868 by Projekt Citybanan, on Flickr


_MG_8955 by Projekt Citybanan, on Flickr


_MG_9052 by Projekt Citybanan, on Flickr

[Swede]

Originally Posted by NordikNerd

http://www.svt.se/nyheter/lokalt/stockholm/ny-tunnelbanestation-i-hagalund


Now it is clear that there will be a metro station in Hagalund, which the politicians in the Stockholm suburb Solna long wanted.

On march 6th the new metro station Hagalund was presented, it will be located along the new yellow line and will be built with two entrances.

One of the exits will be situated in the work-areas of Hagalund and along the road Solnavägen and it will mean thousands of new homes, says an enthusiastic mayor.

- It means that this industrial area may become a thriving residential area with a brand new metro station,
but also to our vision of making the Solna road a city street that connects with Hagastaden and the city can become a reality, says Solna Municipal Pehr Gran Falk (M) .

He says that now they can build thousands of homes.

IMO:
Without that station the new Green branch would be 99% insane. Now it's just 90% insane.
The station itself looks to be fairly well placed with exits on either side of the mainline rail tracks. I've been to the area quite a few times and the placement is very smart.
However, the branch remains idiotic. Having it as a branch of the Green line will reduce capacity westwards (only expected to be ok since the huge motorway tunnel "Förbifarten" is expected to make 10% of riders there switch to driving cars) and will make an actual 4th subway line through the City years and years away.

[Swede]

The C20 subway cars that entered service around 2000 will now get a mid-life renovation. Starting in 2019 it'll be 9 cars at a time getting renovated until it's all done in 2022. This is made possible by the delivery of the new C30 cars (so that there won't be a shortage of cars).
Cost: 1.3 billion SEK
New interior layout with more open space and about 1/8 less seats.
New doors.
New info system with info screens in the cars.
New CCTV equipment.
Modernized drivers cabin.
Alco-lock for the drivers.
and new seats, of course. With a new pattern, mimicking the pattern of Sergels Torg instead of having small drawings of Stockholm landmarks.

http://www.stockholmdirekt.se/nyheter/t-...ilder-har/repqcu!NQLAn9QunXjgEwWdTkH23g/

[Swede]

Originally Posted by Swede

Roslagsbanan (the narrow gauge one):

Stockholm - Roslagsbanan - Rolling stock details by Ingolf, on Flickr

http://railcolornews.com/2017/04/24/se-s...omized-emus-for-stockholms-roslagsbanan/

Stadler won out against the competition to build 22 customized electrical multiple units (EMU) for Stockholm Transport (SL). The total contract volume amounts to approximately CHF 232 million. The EMU will be used on the Roslagsbanan route, connecting Stockholm with regions to the north and east of the Swedish capital. The 891 mm track gauge is unique in the world, and Stadler meets the need for a special model: the Swiss rail vehicle manufacturer is well established in the tailor-made sector and continues to generate between 12 and 15 per cent of its group-wide turnover in this area.

Stadler was awarded the contract for the 22 EMU, known as X15p, on 23 August 2016. The cancellation period expired on 21 April. This means Stadler can deliver trains to Sweden once again.

The 22 EMU will be used on the 65-kilometre Roslagsbanan route. The trains are designed for a speed of 120 km/h, and can take 300 passengers, with seats for 150. Furthermore, they are designed to make access easy for passengers with restricted mobility, and also offer more space for prams and bikes. The trains will be delivered in 2020 and will be put into service a year later.

[Swede]

Stockholm's subway is going to see some significant expansions soon. First is a major extension of the Blue line and a small new branch to the Green line. Those are pretty much all decided and funded. No construction yet though. After that it's looking like there'll be a new line that'll have a connection to the Red line i.e. some trains will run partly on one the the Red branches.

Map of current network plus the new Blue line bits in a lighter shade of blue and the new branch of the Green line in yellow (since they're still using the Yellow Line bullsh!t PR stunt name).
Note that the dark blue bit in the south is a currently existing Green branch that will be transferred to being on the Blue line. Two stations (Globen & Enskede Gård) will be closed and replaced by one new one (Slakthusområdet). This transfer of a branch from the Green to the Blue line has been part of long-term plans for decades and is finally happening. It'll make the Green line run better (two branches will be easier to run reliably than three) and give the new bit of the Blue line many instant passengers. I live on this branch and am looking forward to it since it'll mean more frequent service and more even intervals between trains.
The small new bit of Blue line in the north is to serve a new district under construction on an old airbase as well as to connect to the commuter rail at Barkarby Station.
The Yellow branch of the Green line will be a western branch, i.e. the tracks will branch of westwards before turning north, so trains can not run from that new branch to the existing western part of the line. The map is actually incorrect here: there'll be one more station on this branch. Between Hagastaden and Arenastaden there'll be a station Hagalund. A station that makes the branch almost worth it IMO.

http://www.nyatunnelbanan.sll.se/sv/nya-tunnelbanan

The new bits for the southern Blue line:

http://www.nyatunnelbanan.sll.se/sv/nya-tunnelbanan


The northern bit of the Blue line:

http://www.barkarbystaden.se/aktuellt/tyck-till-om-tunnelbanans-strackning-och-utformning

The "Yellow line" branch of the Green line

https://www.svt.se/nyheter/lokalt/stockholm/hagalund-kan-fa-tunnebanestation

[Swede]

The mentioned next phase after that:


https://www.svt.se/nyheter/lokalt/stockholm/sa-har-blir-nya-tunnelbanan-fridhemsplan-alvsjo

A new line running from Älvsjö (commuter rail and bus hub) to Fridhemsplan (secondary subway hub). Via the new district that's soon to be u/c at Årstafältet and via Årstaberg (which'll also see significant densification) and via Liljeholmen (also a seconday subway hub).
There'll be space on the tracks for more trains than just that little line demands so a connection to the Red line will be made that'll allow for some trains fromthe southwestern Red branch to go to Fridhemsplan instead of via the central station towards the northeast.
No intermediary station between Liljeholmen and Fridhemsplan is planned. Which is strange since the distance is quite long. One or even two stations would make sense.

[Swede]

My commentary:

GAH! Get a long-term plan already! Obviously there are no new long-term plans since the 60s. The yellow branch ought to be a full new 4th subway line that should include most of the new Red line. Though IMO it ought to not do that huge sharp western bend and instead go straight under the inner city with new transfer stations to all the other lines (and commuter rail) on it's way. This would line up pretty nicely and create a line that would alter the hub-and-spoke set up of the network far more than the current plans.
here's how I'd do it (with some more ideas for other rail infra extensions added: https://www.google.se/maps/@59.321042,18...3!4m2!6m1!1s12uhragtMomMe1tCnqOl8IqwobEo

I'm not doubting the actual professional planners (that much). I'm just seeing so many small fairly short-term deals made by politicians that sabotage good things coming from this.

[Swede]

As part of the same funding package as the new Red line branches there's two more major investments in rail transit that are now practiacally decided on.

First is that Roslagsbanan (the narrow gauge railway getting new cars just a few posts above this post) will be getting a new tunnel running from Universitetet to Centralen via Odenplan. I.e. the current city-end terminal will close permanently (and the land there redeveloped with mostly residentials) and be replaced with a tunnel that goes a very different route and that reaches all the way to Sweden's main transit hub.
Cost: 7.1G SEK
As part of the deal the City of Stockholm commits to building 500 residential units (yes 500. not 5 000 or 50 000. 500.). Vallentuna municipality 5 650, Österåker municipality 7 020 & Täby municipality 16 200.

New map for that railway:

source




Second is Tvärbana Syd. i.e. ~ the Southern Orbital. An LRT line connecting suburbs on the Red Line subway and on the commuter rail line to Södertälje. A further extension eastwards from Älcjö to Skarpnäck or even to Älta or Värmdö have been talked about for years already and has large local political support in those areas. Will likely use the same cars, signalling, etc. as the current LRT line Tvärbanan. Even though no connection is currently planned. Such a connection has been suggested by politicians though and in the long term I think it'll get built.
Cost: 4.2G SEK
Huddinge municipality commits to building 18 500 residential units.


source

[Swede]

Update video about the new RORO & container port under construction just outside Nynäshamn at the southern tip of the Stockholm metropolitan area.
• Video Link

[Swede]

The first of the new C30 subway cars has left the factory. It'll go through testing down on the continent til the end of the year and arrive up here at around newyears. For more local testing before being put into service. The whole batch of 96 cars will be delivered by 2021.

http://www.sll.se/verksamhet/kollektivtr...er/2017/05/Forsta-C30-lamnar-verkstaden/

[Swede]

Citybanan will open in just 3 days! I remember when it was still a hotly debated plan with the then right-wing government de-funding it before protests from the whole region got too loud.

A couple of pics I took yesterday of the stairs & escalators going down to Citybanan from the Blue line level at T-Centralen:


IMG_20170706_170931 by Gustav Svärd, on Flickr


IMG_20170706_170806 by Gustav Svärd, on Flickr

How the map deals with the new interchange at Odenplan:

IMG_20170705_163206 by Gustav Svärd, on Flickr

[Aylmer]

Thanks for posting all theses updates and pictures - The work going on in Stockholm is a real inspiration!

[Swede]

Citybanan is now OPEN! Has been for a couple of weeks, even.

• Video Link
(not mine)

I've used it twice and passed through it twice. Looks good and IMO easy to navigate. The signage needs some improvement at the platform level though 1) point you to where a short train is along the platform (looong platforms) and 2) tell you when a train is leaving as well as if it is at the station (the trains usually wait a few minutes at City just like they did before at Centralen). Plus, I didn't see any screens for showing the load in each section of the train, which has been tested for a year or so at at least one other station and worked very well).

Along with the new stations they're changed the signage at the whole T-Centralen / City station.
New diagram of the elevators:


And a diagrammatic map of the same station, to the side of which are numbered pictures of the main artworks at the station. I guess to help people navigate.

[Swede]

Currently the central bit of the Red subway line is out of service. Started a couple of weeks ago (right after Citybanan opened) and will open again tomorrow (is the plan). The reason is that the subway bridge between Slussen and Old town needs work done. That bridge is soon 70 years old and has 5 subway track (4 in regular use for the Red and Green lines) so it needs a lot of love by now.


As for other projects around town...

The #7 tram extension to T-Centralen is slowly moving ahead. No track layed but the track beds are mostly in place since they've been installed as the street they're on has been renovated (it sits on a 1+ level concrete structure). Should open within a couple of years and will be pretty awesome.

The Blue subway line extension is starting to see some site-prep out in Nacka.

Tvärbanan... no real news. So I guess that might be a good thing? No delays of the re-opening announced, at least. 2017-10-01 for the whole line with the newer Solna branch opening before then in august iirc (with 2 stations from the old part joining in at that time too, first through-traffic between the original part and the newish "branch"). Afaik the brand new part to Sickla Station (interchange with Saltsjöbanan) will open on 2017-10-01 too. Having that added and through-traffic for the whole line and beign able to run more frequent trams then before... it'll be like a whole new beast.
